Input parameter reference#

Every parameter the GuPPy GUI exposes, organized to match what you see on screen. The page mirrors the three cards on the homepage (Individual Analysis, Group Analysis, Visualization Parameters) and the visual sub-groupings inside each card. Each row gives the parameter as it appears in the GUI, a one-line description of what it does, the data type, the default value, and the accepted values or range. Prose paragraphs underneath cover the parameters that need more than a single line.

This is a reference, not a tutorial. If you are running GuPPy for the first time, start with Your First Analysis. The defaults documented here are tuned for a typical 1 kHz dual-wavelength CSV recording and work for the tutorial sample data without modification.

The pipeline-step numbering used in this page matches the steps in Your First Analysis: Step 3 (Load the raw data), Step 4 (Preprocess the signal), Step 5 (Compute the PSTH), Step 6 (Visualize the results).

Individual Analysis#

The largest card on the homepage and the only one open by default. The left column holds a flat list of widgets covering data selection, preprocessing, transient detection, output metric selection, and artifact removal. The right column holds four labeled widget boxes for z-score, PSTH, baseline correction, and peak / AUC parameters.

Data source#

Used by: Step 3 (Load the raw data).

Parameter	Description	Type	Default	Options / range
Data Source	Local-folder mode vs DANDI streaming.	radio	`local`	`local`, `dandi`
(file browser)	Session folders to analyze.	list of paths	empty	absolute paths to session directories
(DANDI selector)	DANDI assets to materialize as sessions.	dict	`None` (local mode)	per-session mapping of `dandi://` URIs

Data Source picks between selecting local session folders from the file browser (the common case) and streaming NWB sessions directly from DANDI. The browser is hidden when dandi is selected and the DANDI selector takes its place.

File browser holds the list of session folder paths the pipeline will analyze. Multiple folders are allowed for batch runs; all of them must share a common parent directory or the pipeline raises a validation error before any work starts. The pipeline records the common parent automatically and uses it to anchor output locations; this is not a configurable knob.

DANDI selector is populated only in dandi mode. Each selected DANDI asset URI is materialized into a session directory under a user-chosen output root, and the pipeline records the URI that backed each session.

Compute and batching#

Used by: multiple steps.

Parameter	Description	Type	Default	Options / range
# of cores	How many CPU workers run the pipeline’s per-channel steps in parallel.	int	`2`	positive integer, kept below the host’s core count
Combine Data?	Concatenate two split files into one trace.	bool	`False`	`True`, `False`

# of cores controls the parallelism used during raw-data reading, preprocessing, and PSTH computation, where the pipeline can process channels independently and in parallel. Setting it equal to the number of physical cores on the machine is usually fine; setting it higher than the number of cores does not help.

Combine Data? is for the unusual case where one recording session was split across two data files (for example a system that wrote separate files for two halves of a recording). When True, the pipeline concatenates the matching channels across both files into a single trace before preprocessing.

Signal preprocessing#

Used by: Step 4 (Preprocess the signal).

Parameter	Description	Type	Default	Options / range
Isosbestic Control Channel?	Use the 405 nm channel to remove motion artifacts.	bool	`True`	`True`, `False`
Eliminate first few seconds	Drop the LED-warmup transient at the start.	int	`1`	non-negative seconds
Window for Moving Average filter	Width of the smoothing kernel.	int	`100`	positive integer, in samples (not seconds)

Isosbestic Control Channel? declares whether the recording includes a 405 nm control channel. When True, preprocessing fits the control trace to the signal trace by linear regression and subtracts the fitted control to remove motion artifacts and photobleaching that affect both wavelengths equally. When False, the regression-and-subtract step is skipped and only the signal trace is z-scored. See the isosbestic correction explainer for the underlying biology and math.

Eliminate first few seconds drops this many seconds from the start of every recording. The first second or two of fiber-photometry data is usually contaminated by the bright transient when the LED first turns on; this parameter exists to discard that. Default 1 is conservative.

Window for Moving Average filter is the width of the moving-average smoothing kernel applied to both control and signal traces during preprocessing, expressed in samples, not seconds. The default 100 is appropriate for recordings sampled around 1 kHz; lower it proportionally for slower acquisition rates (for example use 10 for a 100 Hz recording).

Output metric selection#

Used by: Step 4 (Preprocess) writes the metrics; Step 5 (Compute the PSTH) and the transient detector read them.

Parameter	Description	Type	Default	Options / range
z_score and/or ΔF/F? (psth)	Metric Step 5 aligns events on.	str	`z_score`	`z_score`, `dff`, `Both`
z_score and/or ΔF/F? (transients)	Metric the transient detector operates on.	str	`z_score`	`z_score`, `dff`, `Both`
z-score plot and/or ΔF/F plot?	Plot pop-up at the end of Step 4.	str	`None`	`z_score`, `dff`, `Both`, `None`

z_score and/or ΔF/F? (psth) chooses which metric Step 5 uses to align events. Selecting Both writes two complete sets of PSTH outputs, one per metric. See the z-score normalization explainer for what z_score is and how it differs from dff.

z_score and/or ΔF/F? (transients) chooses which metric the transient detector operates on. Same Both semantics.

z-score plot and/or ΔF/F plot? controls the matplotlib plot that pops up at the end of Step 4. None skips the plot; the other options open one window for the chosen metric (or two windows for Both).

Transient detection#

Used by: Step 4 (Preprocess) runs the transient detector on the corrected signal.

Parameter	Description	Type	Default	Options / range
Moving Window for transients detection (s)	Rolling window for the detector.	int	`15`	positive seconds
HAFT	Drop excursions above this multiple of MAD before detection.	int	`2`	positive integer
TD Thresh	Detection threshold, in multiples of MAD above the median.	int	`3`	positive integer

Moving Window for transients detection (s) is the rolling window used by the detector, in seconds.

HAFT (High Amplitude Filtering Threshold) filters out events whose amplitude exceeds this multiple of the trace MAD above the median. The intent is to drop unrealistically large excursions before transient detection, since those are typically motion or recording artifacts that survived preprocessing.

TD Thresh (Transients Detection threshold) is the detection threshold proper: local maxima exceeding this multiple of MAD above the median (computed after the high-amplitude filter) are flagged as transients.

Format-specific (Neurophotometrics)#

Used by: Step 3 (Load the raw data) when the recording is an NPM CSV without Flags or LedState columns.

Parameter	Description	Type	Default	Options / range
Number of channels (Neurophotometrics only)	Manual fallback for stripped NPM CSVs.	int	`2`	positive integer

Number of channels (Neurophotometrics only) is read only when the data is a Neurophotometrics recording whose CSV does not include the Flags or LedState column. Modern NPM recordings include those columns and GuPPy can infer channel structure automatically; this parameter is the manual fallback for older or stripped-down NPM CSVs. Other format-specific behavior (TDT epoc handling, Doric channel selection, NWB recording-extractor selection) is handled by the recording extractors at read time and does not require user-set parameters.

Artifact removal#

Used by: Step 4 (Preprocess) runs the interactive removal flow when enabled.

Parameter	Description	Type	Default	Options / range
removeArtifacts?	Enable the interactive removal flow.	bool	`False`	`True`, `False`
removeArtifacts method	How dropped chunks are handled.	str	`concatenate`	`concatenate`, `replace with NaN`

removeArtifacts? enables the manual artifact-removal step in Step 4: when True, GuPPy presents an interactive plot during preprocessing and lets you select bad chunks to drop. When False, no chunks are removed.

removeArtifacts method chooses how dropped chunks are handled. concatenate removes the bad sections and stitches the surviving good sections together (so the resulting trace is shorter than the input). replace with NaN keeps the trace at its original length but masks the dropped samples with NaN, which downstream code treats as missing.

Z-score Parameters#

Used by: Step 4 (Preprocess) writes the z-score files.

Parameter	Description	Type	Default	Options / range
z-score computation Method	Normalisation formula.	str	`standard z-score`	`standard z-score`, `baseline z-score`, `modified z-score`
Baseline Window Start Time (s)	Start of the baseline window for `baseline z-score`.	int	`0`	seconds, must be `< Baseline Window End Time` and within the signal’s recorded timespan
Baseline Window End Time (s)	End of the baseline window for `baseline z-score`.	int	`0`	seconds, must be `> Baseline Window Start Time` and within the signal’s recorded timespan

z-score computation Method picks the normalization formula. standard z-score uses the mean and standard deviation across the entire trace. baseline z-score uses the mean and standard deviation of a user-specified window (the baseline window parameters below). modified z-score uses the median and median absolute deviation, which is robust to outliers and to long tonic shifts. See the z-score normalization explainer for the formulas and trade-offs.

Baseline Window Start Time (s) and Baseline Window End Time (s) define the baseline window in seconds. Both default to 0, which is the sentinel meaning “no window set”; you only need non-zero values when the z-score method is baseline z-score. The validator enforces start < end, both finite numbers, and both within the signal’s actual timespan, surfacing a descriptive error if any of those conditions fail.

PSTH Parameters#

Used by: Step 5 (Compute the PSTH).

See the PSTH explainer for what these parameters configure (the peri-event window, event-timestamp deduplication, binning across events) and the reasoning behind the default values.

Parameter	Description	Type	Default	Options / range
Seconds before 0	Pre-event window edge.	int	`-10`	typically negative; defines the pre-event window
Seconds after 0	Post-event window edge.	int	`20`	typically positive; defines the post-event window
Compute Cross-correlation	Cross-correlate PSTHs across regions.	bool	`False`	`True`, `False`. Requires at least two distinct signal regions; raises `ValueError` otherwise.
Time Interval (s)	Minimum spacing for accepted event timestamps.	int	`2`	seconds; bursts of event timestamps closer than this are discarded as duplicates
Bin PSTH trials	Binning unit (time vs count).	str	`Time (min)`	`Time (min)`, `# of trials`
Time(min) / # of trials for binning	Bin size; `0` disables binning.	int	`0`	`0` disables binning; positive values use the unit selected above

Seconds before 0 and Seconds after 0 define the peri-event window. Defaults give a 30-second window from 10 s before to 20 s after each event timestamp.

Compute Cross-correlation turns on cross-correlation between PSTHs of two distinct signal regions, useful for detecting coordinated activity between brain areas. The pipeline raises a descriptive ValueError when this is True but only one signal region is configured. See the cross-correlation explainer for interpretation guidance.

Time Interval (s) suppresses bursts of event timestamps. If two event timestamps in the input are closer than this number of seconds, the second one is dropped before PSTH alignment, preventing double-counted overlapping windows.

Bin PSTH trials and Time(min) / # of trials for binning together control binning of the resulting PSTH. With Bin PSTH trials = "Time (min)" and the bin size set to 5, the PSTH is averaged into 5-minute bins along the trial axis; with # of trials and bin size 10, bins of 10 trials each. Setting the bin size to 0 disables binning entirely.

Baseline Parameters#

Used by: Step 5 (Compute the PSTH) when correcting per-event offsets.

Parameter	Description	Type	Default	Options / range
Baseline Correction Start time	Start of the per-event baseline subtraction window.	int	`-5`	seconds, within `[Seconds before 0, Seconds after 0]`
Baseline Correction End time	End of the per-event baseline subtraction window.	int	`0`	seconds, within `[Seconds before 0, Seconds after 0]` and `> Baseline Correction Start time`

These two parameters define a baseline window inside the PSTH window. The mean of each event-aligned trace within this baseline is subtracted from that trace before averaging, removing per-event offsets so that all event-aligned traces are centered on the same baseline.

Set both to 0 to disable baseline correction. If the first event timestamp in the recording is closer to the start of the trace than Baseline Correction Start time - Seconds before 0 seconds, that event is rejected because its baseline window would fall outside the recording.

Peak and AUC Parameters#

Used by: Step 5 (Compute the PSTH) computes peak amplitude and area under the curve for each window.

Parameter	Description	Type	Default	Options / range
Peak Start time	Start times for the peak/AUC windows.	list of int	`[-5, 0, 5]` (rows 1-3 of the table; rows 4-10 are NaN)	one or more start times in seconds, within `[Seconds before 0, Seconds after 0]`
Peak End time	End times paired with the starts.	list of int	`[0, 3, 10]` (rows 1-3 of the table; rows 4-10 are NaN)	one or more end times in seconds, paired with starts

The peak / AUC widget is a small table with rows of (start, end) pairs. Each row defines a window inside the PSTH within which GuPPy computes the peak amplitude and area under the curve of the trial-mean trace. Multiple rows let you measure the same PSTH across multiple windows in a single run (for example, an early [-5, 0] baseline window, an immediate post-event [0, 3] window, and a later [5, 10] window). The tabulator widget accepts up to ten rows; rows whose start or end value is NaN are ignored.

Group Analysis#

Collapsed by default on the homepage. Configures cross-session averaging.

Used by: Step 5 (Compute the PSTH) writes the averages when enabled.

Parameter	Description	Type	Default	Options / range
(file browser)	Session folders to include in the cross-session average.	list of paths	empty	absolute paths to session directories
Average Group?	Write averaged outputs to `average/`.	bool	`False`	`True`, `False`

File browser is the list of session folders to include in the cross-session average. Distinct from the Individual-Analysis browser so you can run individual analyses and group analyses against different folder sets in the same configuration.

Average Group? must be True for Step 5 to write averaged outputs into the average/ directory. If False, PSTH outputs are per-session only.

Visualization Parameters#

Collapsed by default on the homepage. Configures Step 6.

Used by: Step 6 (Visualize the results).

Parameter	Description	Type	Default	Options / range
z-score or ΔF/F? (for visualization)	Which metric the Visualization GUI plots.	str	`z_score`	`z_score`, `dff`
Visualize Average Results?	Show cross-session averages instead of per-session.	bool	`False`	`True`, `False`

z-score or ΔF/F? (for visualization) picks which metric the Visualization GUI plots. Must match a metric that Step 4 actually wrote: if you ran preprocessing with the PSTH metric set to z_score and try to visualize dff, GuPPy raises a descriptive error pointing at the missing files.

Visualize Average Results? decides whether the Visualization GUI shows individual-session results or the cross-session averages produced by Step 5 with Average Group? set to True. Single-session analyses should leave this False.

Internal name index#

This index is for readers who arrive with an internal parameter name in hand and need to find the corresponding GUI parameter. That happens in four situations:

Reproducing or auditing a past analysis by reading the GuPPyParametersUsed.json snapshot that GuPPy writes after every run; the JSON is keyed by internal names.
Writing a headless or scripted analysis against the API in src/guppy/testing/api.py, which takes a dict keyed by these names.
Debugging a validator or pipeline error, since error messages cite the internal name (for example baselineWindowEnd=120 exceeds signal duration 90.5s).
Reading or contributing to the source code, where parameter accesses go through the internal names.

The table is sorted alphabetically by internal name. Each row links to the section above where the parameter is documented in full. Internal-only keys that have no GUI counterpart (abspath) are listed too.

Internal name	Parameter	Section
`abspath`	(auto-derived; not user-set)	Data source
`artifactsRemovalMethod`	removeArtifacts method	Artifact removal
`averageForGroup`	Average Group?	Group Analysis
`baselineCorrectionEnd`	Baseline Correction End time	Baseline Parameters
`baselineCorrectionStart`	Baseline Correction Start time	Baseline Parameters
`baselineWindowEnd`	Baseline Window End Time (s)	Z-score Parameters
`baselineWindowStart`	Baseline Window Start Time (s)	Z-score Parameters
`bin_psth_trials`	Time(min) / # of trials for binning	PSTH Parameters
`combine_data`	Combine Data?	Compute and batching
`computeCorr`	Compute Cross-correlation	PSTH Parameters
`dandi_uri_map`	(DANDI selector)	Data source
`filter_window`	Window for Moving Average filter	Signal preprocessing
`folderNames`	(file browser, Individual Analysis)	Data source
`folderNamesForAvg`	(file browser, Group Analysis)	Group Analysis
`highAmpFilt`	HAFT	Transient detection
`isosbestic_control`	Isosbestic Control Channel?	Signal preprocessing
`mode`	Data Source	Data source
`moving_window`	Moving Window for transients detection (s)	Transient detection
`nSecPost`	Seconds after 0	PSTH Parameters
`nSecPrev`	Seconds before 0	PSTH Parameters
`noChannels`	Number of channels (Neurophotometrics only)	Format-specific (Neurophotometrics)
`numberOfCores`	# of cores	Compute and batching
`peak_endPoint`	Peak End time	Peak and AUC Parameters
`peak_startPoint`	Peak Start time	Peak and AUC Parameters
`plot_zScore_dff`	z-score plot and/or ΔF/F plot?	Output metric selection
`removeArtifacts`	removeArtifacts?	Artifact removal
`selectForComputePsth`	z_score and/or ΔF/F? (psth)	Output metric selection
`selectForTransientsComputation`	z_score and/or ΔF/F? (transients)	Output metric selection
`timeForLightsTurnOn`	Eliminate first few seconds	Signal preprocessing
`timeInterval`	Time Interval (s)	PSTH Parameters
`transientsThresh`	TD Thresh	Transient detection
`use_time_or_trials`	Bin PSTH trials	PSTH Parameters
`visualize_zscore_or_dff`	z-score or ΔF/F? (for visualization)	Visualization Parameters
`visualizeAverageResults`	Visualize Average Results?	Visualization Parameters
`zscore_method`	z-score computation Method	Z-score Parameters
